ASUS IoT APC-125U Panel PC with ultra-slim design, Intel Core Ultra processor, 22–40mm narrow bezels, 50mm thickness, touchscreen display, in a semiconductor factory setting.

ASUS IoT APC-125U Panel PCs

Ultra-Slim.
Driving Efficiency.

Intel® Core™ Ultra | Rich I/O | 15"/17"/21.5" Options

  • Icon with two hands pointing at each other inside a circle, labeled 'P-CAP Touch.' Set against a dark blue, abstract background.

    P-CAP Touch

  • Shield icon with a water droplet and text 'IP66 Front' signifies water and dust resistance, set against a dark blue gradient background.

    IP66 Front

Engineered for efficiency, built to Last

ASUS IoT APC-125U-series panel PCs deliver real-time control with ultra-slim, fanless performance — powered by Intel® Core™ Ultra 5 with built-in NPU. Available in 15, 17, and 21.5-inch models with 4:3 or 16:9 industrial P-CAP touchscreens, every APC-125U model offers clear visuals and smooth input. The IP66-rated aluminum front ensures durability in harsh settings. With rich native I/O, dual 2.5GbE LAN, wide voltage support, and optional ASUS expansion modules, APC-125U provides versatile, high-speed connectivity for HMI, MES, and control applications.
  • Blue gradient background with Intel Core Ultra 5 logo and text 'Intel® Core™ Ultra Performance', highlighting high-performance computing for ASUS IoT Panel PCs.

    Intel® Core™ Ultra Performance

  • ASUS IoT Panel PC showcasing ultra-slim industrial design, with circular insets highlighting 40mm and 22mm bezel dimensions on the left.
    ASUS IoT Panel PC showcasing ultra-slim industrial design, a 50mm thick metallic chassis on the right.

    Ultra-slim
    industrial design

  • Icon of a gear with connected nodes on a blue gradient background, labeled 'Versatile I/O and expansion,' highlighting ASUS IoT Panel PC adaptability and modular connectivity.

    Versatile I/O
    and expansion

  • Triangle with a lightning bolt indicating electricity, labeled '9V' to '36V,' overlaid on a blue gradient background. Text reads 'Wide voltage support.'

    Wide voltage support

  • ASUS IoT Panel PC front view showing a black screen with a shield icon labeled 'IP66' and a water drop symbol, highlighting front IP66 waterproof and dustproof protection.

    Front IP66 Protection

Accelerated computing for industrial visualization

Powered by the latest Intel® Core™ Ultra 5 125U processor, the ASUS IoT APC-125U series brings next-level computing and graphics performance to industrial panel PCs. These models ensure smoother data processing, faster HMI response, and greater system efficiency. With the Intel Arc Xe-LPG GPU, graphics performance improves by up to 50% compared to previous generations — ideal for dashboards, machine interfaces, and monitoring. Its energy-efficient design also reduces power use by up to 20%, supporting reliable 24/7 operation.
ASUS IoT Panel PC performance illustration showing a tablet with Intel Core Ultra 5 logo, highlighting 1.5x graphics performance and 1.2x power efficiency improvements for industrial applications.

  • Graphics Performance

    150%

  • Power Efficiency

    120%

Industrial-grade connectivity with modular flexibility

The APC-125U series delivers high-speed I/O performance with four LAN ports, including dual 2.5GbE LAN for demanding, data-driven tasks like machine vision, MES systems, and web-based control terminals. With a USB-rich interface — offering six USB ports and two COM ports – these powerful panel PCs support seamless peripheral integration. Two M.2 slots (B-Key and E-Key) enable modular expansion through ASUS expansion modules, ensuring scalable connectivity for future needs. A remote power connector adds installation flexibility for diverse industrial networking scenarios.
ASUS IoT APC Panel PC rear view showing multiple ports, including 2 COM, 4 LAN, and 6 USB, connected to devices like PLC, cameras, and servers, with labels indicating SCADA and cloud connectivity. ASUS IoT APC Panel PC rear view showing multiple ports, including 2 COM, 4 LAN, and 6 USB, connected to devices like PLC, cameras, and servers, with labels indicating SCADA and cloud connectivity.

1Computer monitor icon labeled 'SCADA,' representing industrial control.SCADA

2Simple black cloud outline with the word 'Cloud.'Cloud

3Server tower icon with the words 'Local Server.'Local Server

42 x COM
Square icon with 'PLC' text, representing a programmable logic controller.PLC
Square sensor icon emitting waves with the word 'Sensor.'Sensor

54 X LAN
Camera icon with the text '3 X Camera.'3 x Camers

66x USB
Handheld barcode scanner icon with the word 'Scanner.'Scanner
Printer icon with paper and the word 'Printer.'Printer

7romote power connector

Slim. Tough. Ready for integration.

ASUS IoT Panel PC with a large touchscreen embedded in factory production equipment on a modern smart manufacturing line
Close-up of an ASUS IoT Panel PC corner, highlighting its ultra-slim 40mm depth and 22mm narrow bezel with measurement arrows.
ASUS IoT Panel PC with ribbed metal housing, multiple I/O ports, and a 50mm slim chassis profile highlighted by a measurement line.
ASUS IoT Panel PC shown fitting flush into a rectangular panel-mount layout, with a waterproof rubber seal and ample space between cables and mounting walls.
The APC-125U series features an ultra-slim chassis of around 50 mm and ultra-narrow 22mm bezels — nearly half the previous width — to fit seamlessly into machines with limited front-panel space. The full-flat front panel with IP66-rated protection and rugged aluminum housing ensures durability in industrial settings. Its panel-mount-ready rectangular layout, paired with a waterproof rubber seal and ample space between cables and mounting walls, enables easy, secure integration in harsh environments.

Applications

Conveyor belt with clear glass vials lined up in rows, moving through a sterile, industrial setting. The scene conveys efficiency and precision.

Cleanroom compliance meets reliable performance

APC-125U industrial panel PCs deliver reliable performance in pharmaceutical machinery, with IP66 protection and low power usage for clean, regulated spaces. They support remote control and 24/7 operation.

Key features:

IP66 waterproof/dustproof front panel

Low-power CPU with efficient thermal design

Multiple mounting options

Remote control via mobile devices

24/7 stable performance

A worker in a hard hat interacts with a transparent screen displaying robotic and analytical data in an industrial setting, conveying innovation.

Real-time visibility for smart manufacturing

APC-125U series integrates factory systems into a unified platform for real-time production monitoring, improving operational efficiency and quality control in MES environments.

Key features:

High-density I/O and multi-protocol support

Wide-temperature tolerance

High reliability for continuous operation

Real-time data feedback to minimize downtime

Reduces human error and improves quality control
