P8Z77-V LX2

    Product Image

    Superior graphics performance on Z77

    • DIGI+ VRM Digital Power Design
    • USB 3.0 Boost - Lightning Fast Transfer Speeds!
    • Network iControl - Real-time Network Bandwidth Control
    • GPU Boost - Instant iGPU Level Up!
    • ASUS EPU - Energy Efficiency All Around
    • Windows 8 Ready – Assured Compatibility

    CPU, Chipset and Graphics Features

    LGA1155 Intel® 3rd/2nd Generation Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors Ready

    This motherboard supports Intel® 3rd generation Intel® Core™ processor-based platform and 2nd generation Core™ i7/i5/i3/Pentium®/Celeron® processors, with iGPU, memory and PCI Express controllers integrated to support onboard graphics output with dedicated chipsets, 2-channel (4 DIMM) DDR3 memory and 16 PCI Express 3.0/2.0 lanes. This provides great graphics performance. Intel® 3rd generation Intel® Core™ processor-based platform and 2nd generation Core™ i7/i5/i3/Pentium®/Celeron® processors are among the most powerful and energy efficient CPUs in the world.

    Intel® Z77 Express Chipset

    The Intel® Z77 Express Chipset is a single-chipset design to support socket 1155 Intel® 3rd generation Intel® Core™ processor-based platform and 2nd generation Core™ i7/i5/i3/Pentium®/Celeron® processors. It provides improved performance by utilizing serial point-to-point links, allowing increased bandwidth and stability. Additionally, Z77 chipset provides 4 USB 3.0 ports for 10 times faster data retrieval speed. Moreover, Intel® Z77 Express Chipset can also enable iGPU function, letting users enjoy the latest Intel® integrated graphic performance.

    Intel® Smart Response Technology

    SSD Speed with HDD Capacity
    Intel® Smart Response Technology boosts overall system performance by using an installed fast SSD (min 18.6GB available capacity required) as a cache for frequently accessed data. Key benefits include reduced load and wait times, and lower power consumption through the elimination of unnecessary hard drive spin. This technology combines SSD performance with hard drive capacity, operating up to 6X faster than a hard drive-only system.

    Intel® Smart Connect Technology

    Auto Application Refresh. Less Waiting Time
    Your computer can receive web updates with fresh content for selected applications, even when the system is in sleep mode. This means less time waiting for applications to update and sync with the cloud, leading to a more efficient computing experience.

    Intel® Rapid Start Technology

    Instant Awake your PC from Sleep Mode
    Allows your computer to quickly resume from a low-power hibernate state in seconds. Saving your system memory to the designated SSD, it provides your computer a faster wake-up response time, while still keeping the energy use low.

    Dual-Channel DDR3 2400(O.C.)/2200(O.C.)/2133(O.C.) /2000(O.C.)/1866(O.C.)/1600/1333/1066 MHz Support

    The motherboard supports DDR3 memory that features data transfer rates of DDR3 2400(O.C.)/ 2200(O.C.)/2133(O.C.)/2000(O.C.)/1866(O.C.)/1600/ 1333/1066 MHz to meet the higher bandwidth requirements of the latest 3D graphics, multimedia and Internet applications. The dual-channel DDR3 architecture enlarges the bandwidth of your system memory to boost system performance.

    PCIe 3.0 Ready

    PCI Express® 3.0 (PCIe 3.0) is the latest PCI Express bus standard with improved encoding schemes that provide twice the performance of current PCIe 2.0. Total bandwidth for a x16 link reaches a maximum of 32GB/s, double the 16GB/s of PCIe 2.0 (in x16 mode). As such, PCIe 3.0 provides users unprecedented data speeds, combined with the convenience and seamless transition offered by complete backward compatibility with PCIe 1.0 and PCIe 2.0 devices. PCIe 3.0 will become a must-have feature for users who wish to improve and optimize graphic performance, as well as have the latest technology available to them.

    * PCIe 3.0 speed is supported by Intel® 3rd generation Core™ processors.

    ASUS Exclusive Features

    Digital Power Design for the CPU and iGPU

    All-new digital CPU power controls work perfectly together to match digital power signal (SVID) requests from the CPU, with ultra-fast sensing and response efficiently delivering precision power. Accurate delivery reduces waste, and provides more stable CPU Vcore voltages. Users can adjust CPU PWM voltages and frequencies for various overclocking scenarios, with accurate input through UEFI BIOS tuning or the exclusive ASUS interface. This proprietary design increases overclocking headroom to push performance to its full potential.


    USB 3.0 Boost

    Accelerated USB 3.0 Data Transfer Rates with ASUS USB 3.0 Boost Technology
    With USB 3.0 Boost technology, USB transfer speeds are significantly increased up to 132%, enhancing an already impressive USB 3.0 transfer rate. ASUS software automatically accelerates data speeds for compatible USB 3.0 peripherals without the need for any further user configuration. > Click Here to Learn More

    EPU

    Energy Efficiency All Around
    Tap into the world's first real-time PC power saving chip through a simple onboard switch or AI Suite II utility. Get total system-wide energy optimization by automatically detecting current PC loadings and intelligently moderating power consumption. This also reduces fan noise and extends component longevity!

    Network iControl

    Real-time Network Bandwidth Control
    With a single-click on/off button, the application currently in use has its data and network bandwidth prioritized over other programs. Moreover, you can prioritize your favorite software easily by configuring profiles through the intuitive user interface. Within the profile, programs can be pre-scheduled to run in a specific time period to avoid network congestion and long-waits on downloads. Auto PPPoE network connection provides a one-step setup for enhanced online convenience. Overall, it's an intuitive network bandwidth control center.

    GPU Boost

    Go to the Limit with iGPU Level Up!
    GPU Boost accelerates the integrated GPU for extreme graphics performance. The user-friendly interface facilitates flexible frequency adjustments. It easily delivers stable system-level upgrades for every use.

    HDMI Support

    Enjoy Full HD 1080p Multimedia Home-Theater Entertainment
    High-Definition Multimedia Interface (HDMI) is a set of digital video standards that delivers multi-channel audio and uncompressed digital video for full HD 1080p visuals and 3D animation through all high speed HDMI cable with 3D devices. Supporting HDCP copy protection such as HD DVD and Blu-ray Discs, HDMI provides you with the highest-quality home theater experience.

    AI Suite II

    One-stop Access to Innovative ASUS Features
    With its user-friendly interface, ASUS AI Suite II consolidates all the exclusive ASUS features into one simple to use software package. It allows users to supervise overclocking, energy management, fan speed control, voltage and sensor readings, and even interact with mobile devices via Wi-Fi. This all-in-one software offers diverse and ease to use functions, with no need to switch back and forth between different utilities.

    ASUS UEFI BIOS (EZ Mode)

    Flexible and Easy BIOS Interface
    ASUS UEFI BIOS offers a user-friendly interface that goes beyond traditional keyboard-only BIOS controls to enable more flexible and convenient mouse input. Users can easily navigate the UEFI BIOS with the smoothness of their operating system. Quick and simple overclocking and setup sharing is facilitated by the F12 hotkey BIOS snapshot feature. The exclusive EZ Mode displays frequently-accessed setup info, while the Advanced Mode is for experienced performance enthusiasts that demand far more intricate system control, including detailed DRAM information.

    Supports Hard Drives over 2.2TB
    ASUS UEFI BIOS natively supports hard drives larger than 2.2TB in 64-bit, with full storage space utilization helping deliver far more exciting computing than traditional BIOS versions.

    P8Z77-V LX2 Product Overview
